ZL491 Mechanical Seals

ZLSEALS is a professional China ZL491 Mechanical Seals manufacturer and supplier. The company has a large number of advanced mechanical seals and mechanical seal material testing equipment to ensure that all products reach the international advanced level.

Send Inquiry

Product Description


ZL491 Mechanical Seal Supplier and Manufacturer

Description
As the professional manufacturer, we would like to provide you ZL491 Mechanical Seals. We integrate special designing, researching & manufacturing,which offer ODM&OEM service.
For industrial pumps
Replacing the mechanical seal of Burgmann and John Crane

Operational Conditions:
Temperature:-20℃ to +180℃
Pressure: ≤2.5MPa
Speed: ≤15m/s

Materials:
Stationary Ring: Carbon, Silicon Carbide
Rotary Ring: Ceramic, Silicon Carbide
Secondary Seal: NBR, EPDM, Viton
Spring and Metal Parts: Steel

Applications:
Clean water,
Sewage water
Oil and other moderately corrosive fluids


d(mm) D1 D2 D3 L1 L2
16 27 23 29 30 6.6
18 33 27 32.3 30 7.5
20 35 29 34.3 30 7.5
22 37 31 363 30 7.5
24 39 33 38.3 30 7.5
25 40 34 39.3 30 7.5
28 43 37 42.3 35 7.5
30 45 39 44.3 35 7.5
32 48 42 46.3 35 7.5
33 48 42 47.9 35 7.5
35 50 44 49.5 35 7.5
38 56 49 54.3 35 9
40 5O 51 56.1 35 9
43 61 54 59.1 35 9
45 63 56 61.1 35 9
48 66 59 64.1 35 9
50 70 62 66.1 35 9.5
53 73 65 71 35 11
55 75 67 71.1 35 11
60 80 72 77.1 35 11
65 85 77 83 35 11
68 90 81 91 35 11.3
70 92 O0
0
86.1 35 11.3
75 97 88 98.4 48 11.3
80 105 95 104.8 48 12
85 110 100 108 48 12
90 115 105 114.3 48 14
100 125 115 123.8 48 14
