ZL 250 Mechanical Seals

As the professional manufacturer, we would like to provide you ZL 250 Mechanical Seals. We integrate special designing, researching & manufacturing,which offer ODM&OEM service.

Send Inquiry

Product Description


ZLSEALS is a professional China ZL 250 Mechanical Seals manufacturer and supplier. The company has a large number of advanced mechanical seals and mechanical seal material testing equipment to ensure that all products reach the international advanced level.

Operational Conditions:
Temperature: -20℃ to +180℃
Pressure: ≤1.0MPa
Speed: ≤15m/s

Materials:
Stationary Ring: Carbon, Silicon Carbide
Rotary Ring: Ceramic, Silicon Carbide
Secondary Seal: NBR, EPDM, Viton
Spring and Metal Parts: Steel

Applications:
Clean water,
Sewage water
Oil and other moderately corrosive fluids



d(mm) D3 D2 D1 d1 L1 L2 L3
20 34 29 35 3 41 13 21
22 36 31 37 3 41 13 21
24 38 33 39 3 43 13 21
25 39 34 40 3 43 13 21
28 42 37 43 3 45 13 21
30 44 39 45 3 45 13 21
32 46 42 48 3 45 13 21
34 47 42 48 3 45 13 21
35 49 44 50 3 49 13 21
38 54 50 56
53 13 21
40 56 52 58
55 13 21
43 59 55 A 4 55 13 21
45 61 57 63 4 55 13 21
48 64 60 66 4 55 13 21
50 66 62 68 4 60 13 21
53 69 65 71 4 61 13 21
55 71 67 73 4 61 13 21
58 76 70 79 4 63 16 24
60 78 72 81 4 63 16 24
63 81 75 84 4 63 16 24
65 83 77 86 4 67 16 24
68 87 81 90 4 67 16 24
70 90 83 92 4 68 16 24
75 95 83 97 4 72 16 24
80 100 96 105 4 72 16 24
85 105 101 110 4 77 16 24
90 112 106 115 4 77 16 24
95 119 111 120 4 82 16 24
100 124 116 125 4 82 16 24

Hot Tags: ZL 250 Mechanical Seals, China, Manufacturer, Supplier, Factory, Buy, Customized, Cheap
